Addgene

pNUT3
(Plasmid #175744)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 175744 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    mCherry-C1
  • Total vector size (bp) 6384
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    mCherry-CRY2PHR-NoLS (human nuclear factor-κB inducing kinase)
  • Alt name
    pNUT3
  • Species
    Synthetic
  • Insert Size (bp)
    2334
  • Promoter CMV
  • Tag / Fusion Protein
    • mCherry

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BspEI (unknown if destroyed)
  • 3′ cloning site XhoI (unknown if destroyed)
  • 5′ sequencing primer CMVf: CGCAAATGGGCGGTAGGCGTG
  • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pNUT3 was a gift from Yubin Zhou (Addgene plasmid # 175744 ; http://n2t.net/addgene:175744 ; RRID:Addgene_175744)
  • For your References section:

    Optical control of protein delivery and partitioning in the nucleolus. Tan P, Hong T, Cai X, Li W, Huang Y, He L, Zhou Y. Nucleic Acids Res. 2022 Mar 23. pii: 6553118. doi: 10.1093/nar/gkac191. 10.1093/nar/gkac191 PubMed 35325178
