pBS-TRE-tdKatushka2-WPRE
(Plasmid #193337)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 193337 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 193337-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 193337-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    pBluescript SK(+)
  • Backbone manufacturer
    Stratagene
  • Total vector size (bp) 5573
  • Modifications to backbone
    An Xho-Xho fragment containing TRE-SV40 poly A was transferred from pTRE-Tight (Clontech). WPRE was also inserted between a NotI site (not destroyed)
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    tdKatushka2
  • Species
    Modified fluorescent protein
  • Insert Size (bp)
    1497
  • Promoter TRE

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer ATGTCGAGGTAGGCGTGTAC
  • 3′ sequencing primer WPRE-R
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    The tdKatushka2 gene was cloned from pTEC22 (Addgene #30181).

Terms and Licenses

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBS-TRE-tdKatushka2-WPRE was a gift from Takeshi Imai (Addgene plasmid # 193337 ; http://n2t.net/addgene:193337 ; RRID:Addgene_193337)

  • For your References section:

    Automated neuronal reconstruction with super-multicolour Tetbow labelling and threshold-based clustering of colour hues. Leiwe MN, Fujimoto S, Baba T, Moriyasu D, Saha B, Sakaguchi R, Inagaki S, Imai T. Nat Commun. 2024 Jun 25;15(1):5279. doi: 10.1038/s41467-024-49455-y. 10.1038/s41467-024-49455-y PubMed 38918382
