N-terminal 3X Flag Human CASP9 C287A Mutant
(Plasmid #198380)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 198380 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 198380-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 198380-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    pCR3.1
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 4994
  • Total vector size (bp) 6349
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    N-Terminal 3X Flag Human Caspase-9 C287A Mutant
  • Alt name
    CASP-9; ICE-LAP6; Mch6; APAF-3
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1355
  • Mutation
    Changed Cysteine 287 to Alanine to eliminate protease activity
  • GenBank ID
    NM_001229
  • Entrez Gene
    CASP9 (a.k.a. APAF-3, APAF3, ICE-LAP6, MCH6, PPP1R56)
  • Promoter CMV
  • Tag / Fusion Protein
    • 3X Flag (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site XhoI (destroyed during cloning)
  • 5′ sequencing primer CGCAAATGGGCGGTAGGCGTG
  • 3′ sequencing primer TAGAAGGCACAGTCGAGG
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    N-terminal 3X Flag Human CASP9 C287A Mutant was a gift from Hannah Rabinowich (Addgene plasmid # 198380 ; http://n2t.net/addgene:198380 ; RRID:Addgene_198380)

  • For your References section:

    Involvement of CASP9 (caspase 9) in IGF2R/CI-MPR endosomal transport. Han J, Goldstein LA, Hou W, Watkins SC, Rabinowich H. Autophagy. 2021 Jun;17(6):1393-1409. doi: 10.1080/15548627.2020.1761742. Epub 2020 May 25. 10.1080/15548627.2020.1761742 PubMed 32397873
