PBac-15XQUAS-unc84:2XeGFP-3XP3-ECFP
(Plasmid #217614)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 217614 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart

Backbone

  • Vector backbone
    PBac
  • Backbone size w/o insert (bp) 3999
  • Total vector size (bp) 11369
  • Vector type
    PBac

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    15XQUAS-unc84:2XeGFP-3xP3-ECFP
  • Alt name
    QUAS-unc84:GFP
  • Species
    C. elegans (nematode)
  • Insert Size (bp)
    7309
  • GenBank ID
    181480
  • Entrez Gene
    unc-84 (a.k.a. CELE_F54B11.3)
  • Tag / Fusion Protein
    • eGFP

Cloning Information

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Unc-84 originally cloned from pMUH_unc84_2XGFP (Plasmid #46023) by Gilbert L. Henry.

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please visit https://doi.org/10.1101/2024.08.21.608847 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    PBac-15XQUAS-unc84:2XeGFP-3XP3-ECFP was a gift from Carolyn McBride (Addgene plasmid # 217614 ; http://n2t.net/addgene:217614 ; RRID:Addgene_217614)

  • For your References section:

    Odorant receptor coexpression and multi-expression in the dengue mosquito. David D, dos Anjos VL, Kotb SM, Edwards M, Metz HC, Tian D, Zhao Z, Zung JL, Rose NH, McBride CS. Nat Commun (2026). https://doi.org/10.1038/s41467-026-76682-2 10.1038/s41467-026-76682-2
