pSAD-5PSD95-EGFP-SynPhRFP
(Plasmid #217979)

Print

Ordering

This material is available to academics and nonprofits only. Orders shipped outside the U.S. may require additional regulatory approval, as well as a non-refundable export license fee of $85. Please log in to view availability.
Item Catalog # Description Quantity Price (USD)
Plasmid 217979 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 217979-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 217979-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    pSAD
  • Total vector size (bp) 18491
  • Vector type
    G-Deleted Rabies

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert 1

  • Gene/Insert name
    5PSD95-EGFP
  • Alt name
    Postsynaptic Density Protein-EGFP
  • Species
    R. norvegicus (rat)
  • Insert Size (bp)
    2946
  • Entrez Gene
    Dlg4 (a.k.a. Dlgh4, PSD95, Sap90)
  • Promoter None
  • Tag / Fusion Protein
    • EGFP (C terminal on insert)

Cloning Information for Gene/Insert 1

Gene/Insert 2

  • Gene/Insert name
    SynPhRFP
  • Alt name
    Synaptophysin-RFP
  • Species
    M. musculus (mouse)
  • Insert Size (bp)
    1695
  • Entrez Gene
    Syp (a.k.a. A230093K24Rik, Syn, p38)
  • Promoter None
  • Tag / Fusion Protein
    • RFP (C terminal on insert)

Cloning Information for Gene/Insert 2

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pSAD-5PSD95-EGFP-SynPhRFP was a gift from Edward Callaway (Addgene plasmid # 217979 ; http://n2t.net/addgene:217979 ; RRID:Addgene_217979)

  • For your References section:

    Postsynaptic cell type and synaptic distance do not determine efficiency of monosynaptic rabies virus spread measured at synaptic resolution. Patino M, Lagos WN, Patne NS, Miyazaki PA, Bhamidipati SK, Collman F, Callaway EM. Elife. 2023 Dec 14;12:e89297. doi: 10.7554/eLife.89297. 10.7554/eLife.89297 PubMed 38096019
