pJW2332
(Plasmid #253923)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 253923 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart

Backbone

  • Vector backbone
    pDONR221
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 2353
  • Total vector size (bp) 3429
  • Vector type
    Worm Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    12aa linker::mNeonGreen::TEV::3xFLAG::12aa linker
  • Species
    C. elegans (nematode), Synthetic
  • Insert Size (bp)
    1086

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer M13 Forward (tgtaaaacgacggccagt)
  • 3′ sequencing primer M13 Reverse (caggaaacagctatgaccatg)
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

This plasmid contains four unique crRNA sites that can be used for re-editing the initial knock-in and inserting alternate cassettes. See this preprint for details: https://www.biorxiv.org/content/10.1101/2025.05.14.653803v1

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pJW2332 was a gift from Jordan Ward (Addgene plasmid # 253923 ; http://n2t.net/addgene:253923 ; RRID:Addgene_253923)
