1184S4
(Plasmid #256322)

• Purpose: Dual maker SEPARATOR in Anopheles stephensi.
• Depositing Lab: Omar Akbari
• Depositing Organization: University of California, San Diego (UCSD)
  Located in the United States of America
• Publication: A Combined Wolbachia–SEPARATOR Strategy Enables Genetic Male Selection of Anopheles stephensi (unpublished)

Backbone

• Vector backbone: piggyBac (pBac) transposon vector
• Vector type: Insect Expression

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: Unknown

Gene/Insert 1

• Gene/Insert name: Anopheles gambiae dsx_Exon 4 to 6(partial)
• Species: An. gambiae
• Insert Size (bp): 4940
• Tag / Fusion Protein:
  • EGFP

Gene/Insert 2

• Gene/Insert name: DsRed
• Species: Synthetic

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
  • piggyBac Limited Use Label License
• Industry Terms:
  • Not Available to Industry
