|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||26218||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 7773
Vector typeInsect Expression
Growth in Bacteria
Copy numberHigh Copy
SpeciesM. musculus (mouse)
Insert Size (bp)1389
- Cloning method Restriction Enzyme
- 5′ cloning site XhoI (not destroyed)
- 3′ cloning site XbaI (not destroyed)
- 5′ sequencing primer hsp70 F: GAGCGCCGGAGTATAAATAGAG
- 3′ sequencing primer SV40 R: CCATTCATCAGTTCCATAGG (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pJFRC5-5XUAS-IVS-mCD8::GFP was a gift from Gerald Rubin (Addgene plasmid # 26218 ; http://n2t.net/addgene:26218 ; RRID:Addgene_26218)
For your References section:Refinement of Tools for Targeted Gene Expression in Drosophila. Pfeiffer BD, Ngo TT, Hibbard KL, Murphy C, Jenett A, Truman JW, Rubin GM. Genetics. 2010 Aug 9. ():. 10.1534/genetics.110.119917 PubMed 20697123
