FR_HNF1B_A263insGG
(Plasmid #31103)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 31103 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pcDNA5/FRT/TO
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 5150
  • Vector type
    Mammalian Expression ; Flp/FRT
  • Selectable markers
    Hygromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    HNF1B
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1900
  • Mutation
    mutation A263insGG
  • GenBank ID
    NM_001165923
  • Entrez Gene
    HNF1B (a.k.a. ADTKD3, FJHN, HNF-1-beta, HNF-1B, HNF1beta, HNF2, HPC11, LF-B3, LFB3, MODY5, RCAD, T2D, TCF-2, TCF2, VHNF1)
  • Tag / Fusion Protein
    • myc (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer na
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

for Flp mediated site directed integration, tetracycline inducibilty

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    FR_HNF1B_A263insGG was a gift from Gerhart Ryffel (Addgene plasmid # 31103 ; http://n2t.net/addgene:31103 ; RRID:Addgene_31103)
  • For your References section:

    Pattern of genes influenced by conditional expression of the transcription factors HNF6, HNF4alpha and HNF1beta in a pancreatic beta-cell line. Thomas H, Senkel S, Erdmann S, Arndt T, Turan G, Klein-Hitpass L, Ryffel GU. Nucleic Acids Res. 2004 . 32(19):e150. 10.1093/nar/gnh144 PubMed 15520459
