|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||31202||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 5005
Vector typeGateway Donor vector
Growth in Bacteria
Bacterial Resistance(s)Spectinomycin, 50 μg/mL
Copy numberHigh Copy
SpeciesH. sapiens (human)
Insert Size (bp)1200
Entrez GeneMAP2K1 (a.k.a. CFC3, MAPKK1, MEK1, MEL, MKK1, PRKMK1)
- Cloning method Gateway Cloning
- 5′ sequencing primer M13pUC-fwd
- 3′ sequencing primer M13rev (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
The ORF has no Stop codon. This design enables easy recombination into a destination vector to add an epitope tag of choice and Stop codon to the ORF. Do NOT use this plasmid directly for transfections.
A set of 4 custom lentiviral vectors is available (http://www.addgene.org/25895, http://www.addgene.org/25896, http://www.addgene.org/25897, http://www.addgene.org/25890) to be used to express these ORFs in mammalian cells. These plasmids are not included in the kit and must be ordered separately.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pDONR223-MEKDD was a gift from David Root (Addgene plasmid # 31202 ; http://n2t.net/addgene:31202 ; RRID:Addgene_31202)
For your References section:A public genome-scale lentiviral expression library of human ORFs. Yang X, Boehm JS, Yang X, Salehi-Ashtiani K, Hao T, Shen Y, Lubonja R, Thomas SR, Alkan O, Bhimdi T, Green TM, Johannessen CM, Silver SJ, Nguyen C, Murray RR, Hieronymus H, Balcha D, Fan C, Lin C, Ghamsari L, Vidal M, Hahn WC, Hill DE, Root DE. Nat Methods. 2011 Jun 26. ():. 10.1038/nmeth.1638 PubMed 21706014
