(Plasmid #45497)


Item Catalog # Description Quantity Price (USD)
Plasmid 45497 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
  • Backbone size w/o insert (bp) 4151
  • Total vector size (bp) 6766
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number


  • Gene/Insert name
    2.5kb mouse Nkx2.5 enhancer and promoter fragment
  • Species
    M. musculus (mouse)
  • Insert Size (bp)
  • GenBank ID
  • Entrez Gene
    Nkx2-5 (a.k.a. Csx, Nkx-2.5, Nkx2.5, tinman)
  • Promoter 2.5kb Nkx2.5 enhancer and promoter fragment
  • Tag / Fusion Protein
    • EGFP (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SacI (not destroyed)
  • 3′ cloning site KpnI (not destroyed)
  • 5′ sequencing primer pBR322ori-F
  • 3′ sequencing primer EGFP-N; SV40-pA-R
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    2.1 kb murine Nkx2.5 enhancer fragment from Dr. Eric Olson, UT Southwestern, Dallas, TX, by MTA with Children's Hospital, Boston, MA.

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Alternate plasmid name: Nkx2.5 cardiac enhancer-base promoter-eGFP

The full plasmid sequence is approximate and may not be entirely accurate.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pNkx-GFP was a gift from Sean Wu (Addgene plasmid # 45497 ; ; RRID:Addgene_45497)
  • For your References section:

    Developmental origin of a bipotential myocardial and smooth muscle cell precursor in the mammalian heart. Wu SM, Fujiwara Y, Cibulsky SM, Clapham DE, Lien CL, Schultheiss TM, Orkin SH. Cell. 2006 Dec 15;127(6):1137-50. Epub 2006 Nov 22. 10.1016/j.cell.2006.10.028 PubMed 17123591
