PurposeLocalization: Focal Adhesions, Excitation: 505 / 569, Emission: 516 / 581
Full plasmid sequence is not available for this item.
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||57420||Standard format: Plasmid sent in bacteria as agar stab||1||$75 *|
* Login to view industry pricing.
- Backbone size w/o insert (bp) 4750
Vector typeMammalian Expression
Selectable markersNeomycin (select with G418)
Growth in Bacteria
Copy numberHigh Copy
SpeciesM. musculus (mouse)
- Promoter CMV
/ Fusion Protein
- mEos2 (C terminal on backbone)
- Cloning method Unknown
- 5′ sequencing primer CMV-F
- 3′ sequencing primer SV40pA-R (Common Sequencing Primers)
. Excitation = 505 / 569; Emission = 516 / 581
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:mEos2-Talin-N-22 was a gift from Michael Davidson (Addgene plasmid # 57420 ; http://n2t.net/addgene:57420 ; RRID:Addgene_57420)
For your References section:Nanoscale architecture of integrin-based cell adhesions. Kanchanawong P, Shtengel G, Pasapera AM, Ramko EB, Davidson MW, Hess HF, Waterman CM. Nature. 2010 Nov 25;468(7323):580-4. doi: 10.1038/nature09621. 10.1038/nature09621 PubMed 21107430
