LD223
(Plasmid #69190)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 69190 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    Bluescript II SK+
  • Vector type
    Yeast Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Atg23-2EGFP
  • Species
    S. cerevisiae (budding yeast)
  • Insert Size (bp)
    4000
  • Tag / Fusion Protein
    • 2xEGFP (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SacII (not destroyed)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer T7
  • 3′ sequencing primer SP6
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    LD223 was a gift from Zhiping Xie (Addgene plasmid # 69190 ; http://n2t.net/addgene:69190 ; RRID:Addgene_69190)
  • For your References section:

    A fluorescent tool set for yeast Atg proteins. Li D, Song JZ, Shan MH, Li SP, Liu W, Li H, Zhu J, Wang Y, Lin J, Xie Z. Autophagy. 2015;11(6):954-60. doi: 10.1080/15548627.2015.1040971. 10.1080/15548627.2015.1040971 PubMed 25998947
