C1-FKBP(F36V):mCherry-Akt2(K14A)
(Plasmid #72906)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 72906 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 72906-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 72906-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    C1
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    RAC-beta serine/threonine-protein kinase
  • Alt name
    Akt2
  • Species
    H. sapiens (human)
  • Mutation
    K14A mutation
  • Entrez Gene
    AKT2 (a.k.a. HIHGHH, PKBB, PKBBETA, PRKBB, RAC-BETA)
  • Tag / Fusion Protein
    • FKBP(F36V), mCherry (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (unknown if destroyed)
  • 3′ cloning site BamHI (unknown if destroyed)
  • 5′ sequencing primer TAACAACTCCGCCCCATT
  • 3′ sequencing primer cctctacaaatgtggtatggc
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    C1-FKBP(F36V):mCherry-Akt2(K14A) was a gift from Ivan Yudushkin (Addgene plasmid # 72906 ; http://n2t.net/addgene:72906 ; RRID:Addgene_72906)

  • For your References section:

    Localization of mTORC2 activity inside cells. Ebner M, Sinkovics B, Szczygiel M, Ribeiro DW, Yudushkin I. J Cell Biol. 2017 Jan 31. pii: jcb.201610060. doi: 10.1083/jcb.201610060. 10.1083/jcb.201610060 PubMed 28143890
