(Plasmid #73698)


Item Catalog # Description Quantity Price (USD)
Plasmid 73698 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone size w/o insert (bp) 8904
  • Total vector size (bp) 10285
  • Vector type
    Insect Expression ; Drosophila

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number


  • Gene/Insert name
    Neuronal-synaptobrevin:spGFP1–10 chimera
  • Species
    D. melanogaster (fly)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site XbaI (not destroyed)
  • 5′ sequencing primer HSP70
  • 3′ sequencing primer SV40
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    spGFP1–10 was amplified from ace-4 CD4-2 spGFP1–10 (gift of C. Bargmann)
  • Article Citing this Plasmid

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pUAS-syb:spGFP1–10 was a gift from Marco Gallio (Addgene plasmid # 73698 ; ; RRID:Addgene_73698)
  • For your References section:

    Dynamic labelling of neural connections in multiple colours by trans-synaptic fluorescence complementation. Macpherson LJ, Zaharieva EE, Kearney PJ, Alpert MH, Lin TY, Turan Z, Lee CH, Gallio M. Nat Commun. 2015 Dec 4;6:10024. doi: 10.1038/ncomms10024. 10.1038/ncomms10024 PubMed 26635273
