pEZ06
(Plasmid #81130)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 81130 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pACSA
  • Total vector size (bp) 5742

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    GFP
  • Promoter PEZ1

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer GCTTCCGGCTCGTATGTTGTG
  • 3′ sequencing primer TTGGGTAACGCCAGGGT
  • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEZ06 was a gift from Brian Pfleger (Addgene plasmid # 81130 ; http://n2t.net/addgene:81130 ; RRID:Addgene_81130)
  • For your References section:

    Construction of new synthetic biology tools for the control of gene expression in the cyanobacterium Synechococcus sp. strain PCC 7002. Zess EK, Begemann MB, Pfleger BF. Biotechnol Bioeng. 2016 Feb;113(2):424-32. doi: 10.1002/bit.25713. Epub 2015 Sep 3. 10.1002/bit.25713 PubMed 26192329
