pYFP-NEAT1pr_v2-RT
(Plasmid
#97088)
-
PurposeEncodes a HR repair template for knock-in a YFP expression cassette at the promoter of human NEAT1 gene. Best used with px330-NEAT1pr_v2 vector, but also works with px330-NEAT1pr_v1.
-
Depositing Lab
-
Depositing OrganizationUniversity of Western Australia
Located in Australia -
Sequence Information
Ordering
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 97088 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $94 | |
| DNA | 97088-D50 | 50 μg of DNA in Tris buffer | $495 | ||
| DNA | 97088-D100 | 100 μg of DNA in Tris buffer | $585 | ||
Backbone
-
Vector backbonepEGFP-C1
-
Backbone manufacturerClontech
-
Vector typeCRISPR
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameNEAT1pr_v2-RT
-
SpeciesH. sapiens (human)
-
Entrez GeneNEAT1 (a.k.a. LINC00084, NCRNA00084, TP53LC15, TncRNA, VINC)
- Promoter CMV
-
Tag
/ Fusion Protein
- EYFP (C terminal on insert)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site Unknown (unknown if destroyed)
- 3′ cloning site Unknown (unknown if destroyed)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
The left arm of the repair template was cloned into the AseI site. The right arm was cloned into the MluI site. Original EGFP was mutated to EYFP using mutation: L65F, T66G, V69L, S73A, T204Y
DNA (Catalog # 97088-D50)
Purpose
Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.
Delivery
- Amount 50 μg
- Concentration 1 μg/μL
- Pricing $495 USD
- Storage 4 ℃ (short-term) or -20 ℃ (long-term)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Quality Control
Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.
Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.
DNA (Catalog # 97088-D100)
Purpose
Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.
Delivery
- Amount 100 μg
- Concentration 1 μg/μL
- Pricing $585 USD
- Storage 4 ℃ (short-term) or -20 ℃ (long-term)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Quality Control
Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.
Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pYFP-NEAT1pr_v2-RT was a gift from Archa Fox (Addgene plasmid # 97088 ; http://n2t.net/addgene:97088 ; RRID:Addgene_97088) -
For your References section:
Functional dissection of NEAT1 using genome editing reveals substantial localisation of the NEAT1_1 isoform outside paraspeckles. Li R, Harvey AR, Hodgetts SI, Fox AH. RNA. 2017 Mar 21. pii: rna.059477.116. doi: 10.1261/rna.059477.116. 10.1261/rna.059477.116 PubMed 28325845
