|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||104489||Standard format: Plasmid sent in bacteria as agar stab||1||$65|
|AAV1||104489-AAV1||Virus (100 µL at titer ≥ 1×10¹³ vg/mL)|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 4579
- Total vector size (bp) 5932
Vector typeMammalian Expression, AAV
Growth in Bacteria
Growth Strain(s)NEB Stable
Copy numberLow Copy
Alt nameGCaMP3-T302P R303P A317L M374Y D380Y T381R S383T R392G
Alt nameGCaMP3 variant 1561
Alt nameJanelia GCaMP7
SpeciesR. norvegicus (rat), G. gallus (chicken); A. victoria (jellyfish)
Insert Size (bp)1353
- Promoter Synapsin
/ Fusion Protein
- T7 epitope, Xpress tag, 6xHis
- Cloning method Restriction Enzyme
- 5′ cloning site BamHI (not destroyed)
- 3′ cloning site HindIII (not destroyed)
- 5′ sequencing primer ACCACGCGAGGCGCGAGATAG (Common Sequencing Primers)
Terms and Licenses
Articles Citing this Plasmid
Information for AAV1 (Catalog # 104489-AAV1) ( Back to top )
Ready-to-use AAV1 particles produced from pGP-AAV-syn-jGCaMP7b-WPRE (#104489). In addition to the viral particles, you will also receive purified pGP-AAV-syn-jGCaMP7b-WPRE plasmid DNA.Syn-driven jGCaMP7b calcium sensor. jGCaMP7b exhibits the brightest resting fluorescence of the jGCaMP7 variants, and can be used for imaging of small neuronal processes. These AAV preparations are suitable purity for injection into animals.
- Volume 100 µL
- Titer ≥ 1×10¹³ vg/mL
- Pricing $350 USD for preparation of 100 µL virus + $30 USD for plasmid.
- Storage Store at -80℃. Thaw just before use and keep on ice.
- Shipment Viral particles are shipped frozen on dry ice. Plasmid DNA (≥ 200ng) will also be included in the shipment.
Viral Production & Use
- Packaging Plasmids encode adenoviral helper sequences and AAV rep gene, AAV1 cap gene
- Buffer PBS + 0.001% Pluronic F-68
- Serotype AAV1
- Purification Iodixanol gradient ultracentrifugation
Requestor is responsible for compliance with their institution's biosafety regulations. Lentivirus is generally considered BSL-2. AAV is generally considered BSL-1, but may require BSL-2 handling depending on the insert. Biosafety Guide
Viral Quality Control
- Addgene ensures high quality viral vectors by optimizing and standardizing production protocols and performing rigorous quality control (QC) (see a list of our QC assays). The specific QC assays performed varies for each viral lot. To learn which specific QC assays were performed on your lot, please contact us.
- Titer: the exact titer of your sample will be reported on the tube. The titer you see listed on this page is the guaranteed minimum titer. See how titers are measured.
Visit our viral production page for more information.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pGP-AAV-syn-jGCaMP7b-WPRE was a gift from Douglas Kim & GENIE Project (Addgene plasmid # 104489 ; http://n2t.net/addgene:104489 ; RRID:Addgene_104489)
For viral preps, please replace (Addgene plasmid # 104489) in the above sentence with: (Addgene viral prep # 104489-AAV1)
For your References section:High-performance GFP-based calcium indicators for imaging activity in neuronal populations and microcompartments. Dana H, Sun Y, Mohar B, Hulse B, Hasseman JP, Tsegaye G, Tsang A, Wong A, Patel R, Macklin JJ, Chen Y, Konnerth A, Jayaraman V, Looger LL, Schreiter ER, Svoboda K, Kim DS.. bioRxiv 434589 10.1101/434589
