pRSETA-PAGFP
(Plasmid #11911)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 11911 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pRSETA
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 2827
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    pRSETA-PAGFP
  • Alt name
    photoactivatable green fluorescent protein
  • Species
    Aequorea victoria
  • Insert Size (bp)
    720
  • Mutation
    The PAGFP has four mutations (L64F/T65S/V163A/T203H) compared with the Clontech EGFP. The PAGFP also contains an A206K mutation to disrupt dimerization

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer n/a
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The fluorescent protein encoding region contains one of the three substitutions (A206K) suggested by Dr. Roger Tsien. This mutation disrupts fluorescent protein dimerization even at high concentrations. The mutation does not seem to have much effect on the fluorescent properties of the CFP, GFP and YFP versions, so hopefully it will not affect PAGFP too much. The PAGFP A206K mutant does not display obvious fluorescent differences compared with the original, but please bear in mind that I haven't characterized it to the same extent.

The citation for the A206K mutation in fluorescent proteins is Science 2002 296:913.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pRSETA-PAGFP was a gift from Jennifer Lippincott-Schwartz (Addgene plasmid # 11911 ; http://n2t.net/addgene:11911 ; RRID:Addgene_11911)
  • For your References section:

    A photoactivatable GFP for selective photolabeling of proteins and cells. Patterson GH, Lippincott-Schwartz J. Science. 2002 Sep 13. 297(5588):1873-7. 10.1126/science.1074952 PubMed 12228718
