pET-28a_6H-TAQ_E602D
(Plasmid #166944)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 166944 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pET-28a(+)
  • Backbone manufacturer
    Novagen (EMD Millipore)
  • Backbone size w/o insert (bp) 5369
  • Total vector size (bp) 7826
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Growth instructions
    Rosetta (DE3) strain for protein expression
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Thermus aquaticus DNA polymerase
  • Alt name
    TAQ polymerase
  • Species
    Thermus aquaticus
  • Insert Size (bp)
    2499
  • Mutation
    E602D
  • GenBank ID
    J04639
  • Promoter T7
  • Tag / Fusion Protein
    • 6X His (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NdeI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer taatacgactcactataggg
  • 3′ sequencing primer TAGTTATTGCTCAGCGGTGG
  • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    This plasmid was found in our lab stocks. Its original source is not known.
  • Terms and Licenses
  • Industry Terms
    • Not Available to Industry
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pET-28a_6H-TAQ_E602D was a gift from Robert Tjian (Addgene plasmid # 166944 ; http://n2t.net/addgene:166944 ; RRID:Addgene_166944)
  • For your References section:

    Open-source RNA extraction and RT-qPCR methods for SARS-CoV-2 detection. Graham TGW, Dugast-Darzacq C, Dailey GM, Nguyenla XH, Van Dis E, Esbin MN, Abidi A, Stanley SA, Darzacq X, Tjian R. PLoS One. 2021 Feb 3;16(2):e0246647. doi: 10.1371/journal.pone.0246647. eCollection 2021. 10.1371/journal.pone.0246647 PubMed 33534838
