(Plasmid #39868)


Item Catalog # Description Quantity Price (USD)
Plasmid 39868 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
    iRFP protein GAF domain (mutated)
  • Mutation
    F165Y, D232Y, W308R
  • Promoter CMV
  • Tag / Fusion Protein
    • K coil (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site BglII (not destroyed)
  • 5′ sequencing primer ggtaggcgtgtacggtgggag
  • (Common Sequencing Primers)

Resource Information

  • Terms and Licenses
  • Industry Terms
    • Not Available to Industry
  • Article Citing this Plasmid
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pK-GAFm was a gift from Vladislav Verkhusha (Addgene plasmid # 39868 ; ; RRID:Addgene_39868)
  • For your References section:

    A Near-Infrared BiFC Reporter for In Vivo Imaging of Protein-Protein Interactions. Filonov GS, Verkhusha VV. Chem Biol. 2013 Jul 23. pii: S1074-5521(13)00242-1. doi: 10.1016/j.chembiol.2013.06.009. 10.1016/j.chembiol.2013.06.009 PubMed 23891149
