CIB81-pmGFP
(Plasmid #75366)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 75366 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    EGFP-C1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 4700
  • Modifications to backbone
    C-term CaaX prenylation motif at end of EGFP
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CIB1
  • Alt name
    CIB81
  • Species
    A. thaliana (mustard weed)
  • Mutation
    residues 1-81 of CIB1
  • Entrez Gene
    CIB1 (a.k.a. AT4G34530, T4L20.110, T4L20_110, cryptochrome-interacting basic-helix-loop-helix 1)
  • Promoter CMV
  • Tag / Fusion Protein
    • prenylated EGFP (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site AgeI (not destroyed)
  • 5′ sequencing primer CMV promoter
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    CIB81-pmGFP was a gift from Chandra Tucker (Addgene plasmid # 75366 ; http://n2t.net/addgene:75366 ; RRID:Addgene_75366)
  • For your References section:

    Optimized second-generation CRY2-CIB dimerizers and photoactivatable Cre recombinase. Taslimi A, Zoltowski B, Miranda JG, Pathak GP, Hughes RM, Tucker CL. Nat Chem Biol. 2016 Apr 11. doi: 10.1038/nchembio.2063. 10.1038/nchembio.2063 PubMed 27065233
