pET22b_PstS_2
(Plasmid #78199)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 78199 Standard format: Plasmid sent in bacteria as agar stab 1 $65

This material is available to academics and nonprofits only.

Backbone

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Growth instructions
    use BL21 (DE3) for protein expression
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    pstS (A17C,A197C)
  • Species
    E. coli
  • Mutation
    A17C; A197C (please see depositor comment below)
  • Promoter T7

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NdeI (unknown if destroyed)
  • 3′ cloning site XhoI (unknown if destroyed)
  • 5′ sequencing primer T7
  • 3′ sequencing primer T7 terminal
  • (Common Sequencing Primers)

Resource Information

Depositor Comments

Please note- The numbering system used was for the mature natural wild-type PstS protein. The plasmid produces an extra N-terminal methionine so all mutations will be off by 1nt (e.g., A197C =A198C)

The expressed protein is a double-cysteine variant of E. coli phosphate binding protein. The gene encodes the mature protein without the N-terminal signal peptide, but with an N-terminal methionine, for subsequent labeling at the cysteines with two 6-iodoacetamidotetramethylrhodamines per molecule. This adduct is then used as a fluorescent phosphate biosensor, having 10-15-fold fluorescence increase on binding inorganic phosphate with very high affinity.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pET22b_PstS_2 was a gift from Martin Webb (Addgene plasmid # 78199 ; http://n2t.net/addgene:78199 ; RRID:Addgene_78199)
  • For your References section:

    Development of a Reagentless Biosensor for Inorganic Phosphate, Applicable over a Wide Concentration Range. Solscheid C, Kunzelmann S, Davis CT, Hunter JL, Nofer A, Webb MR. Biochemistry. 2015 Aug 18;54(32):5054-62. doi: 10.1021/acs.biochem.5b00449. Epub 2015 Aug 4. 10.1021/acs.biochem.5b00449 PubMed 26199994
