pBAD-KIRIN1-GR
(Plasmid #107417)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 107417 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pBAD
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    KIRIN1-GR
  • Alt name
    KGR1
  • Species
    Synthetic
  • Insert Size (bp)
    1830

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please visit https://www.biorxiv.org/content/early/2018/01/26/254383 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBAD-KIRIN1-GR was a gift from Robert Campbell (Addgene plasmid # 107417 ; http://n2t.net/addgene:107417 ; RRID:Addgene_107417)
  • For your References section:

    Genetically encoded fluorescent indicators for imaging intracellular potassium ion concentration. Shen Y, Wu SY, Rancic V, Aggarwal A, Qian Y, Miyashita SI, Ballanyi K, Campbell RE, Dong M. Commun Biol. 2019 Jan 14;2:18. doi: 10.1038/s42003-018-0269-2. eCollection 2019. 10.1038/s42003-018-0269-2 PubMed 30652129
