pEGFP‐RNASEH1
(Plasmid #108699)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 108699 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pEGFP-N1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 4733
  • Total vector size (bp) 5500
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    RNASEH1 (nuclear isoform)
  • Species
    H. sapiens (human)
  • Entrez Gene
    RNASEH1 (a.k.a. H1RNA, PEOB2, RNH1)
  • Promoter CMV
  • Tag / Fusion Protein
    • GFP (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BglII (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer CMV-F
  • 3′ sequencing primer EGFP-N
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEGFP‐RNASEH1 was a gift from Andrew Jackson & Martin Reijns (Addgene plasmid # 108699 ; http://n2t.net/addgene:108699 ; RRID:Addgene_108699)
  • For your References section:

    PCNA directs type 2 RNase H activity on DNA replication and repair substrates. Bubeck D, Reijns MA, Graham SC, Astell KR, Jones EY, Jackson AP. Nucleic Acids Res. 2011 May;39(9):3652-66. doi: 10.1093/nar/gkq980. Epub 2011 Jan 17. 10.1093/nar/gkq980 PubMed 21245041
