SB_convex
(Plasmid #110104)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 110104 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pBXPHM3
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    scaffold Sybody of the convex library
  • Promoter PBAD
  • Tag / Fusion Protein
    • His (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site unknown (unknown if destroyed)
  • 3′ cloning site unknown (unknown if destroyed)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    SB_convex was a gift from Markus Seeger (Addgene plasmid # 110104 ; http://n2t.net/addgene:110104 ; RRID:Addgene_110104)
  • For your References section:

    Synthetic single domain antibodies for the conformational trapping of membrane proteins. Zimmermann I, Egloff P, Hutter CA, Arnold FM, Stohler P, Bocquet N, Hug MN, Huber S, Siegrist M, Hetemann L, Gera J, Gmur S, Spies P, Gygax D, Geertsma ER, Dawson RJ, Seeger MA. Elife. 2018 May 24;7. pii: 34317. doi: 10.7554/eLife.34317. 10.7554/eLife.34317 PubMed 29792401
