PurposePlasmid encoding the cytosolic localization of the FRET semi-synthetic biosensor measuring NAD+ concentration in mammalian cells
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||113914||Standard format: Plasmid sent in bacteria as agar stab||1||$85|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 11448
- Total vector size (bp) 13797
Vector typeMammalian Expression
Growth in Bacteria
Bacterial Resistance(s)Ampicillin, 100 μg/mL
Copy numberHigh Copy
Insert Size (bp)2349
- Promoter CMV TetO2
- Cloning method Gibson Cloning
- 5′ sequencing primer CMV_Fwd
- 3′ sequencing primer BGH_Rev (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
Plasmid contains some differences in the oriP backbone sequence compared to the depositor sequence. These differences are not known to affect plasmid function.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pEBTet_NAD-Snifit-cyto was a gift from Kai Johnsson (Addgene plasmid # 113914 ; http://n2t.net/addgene:113914 ; RRID:Addgene_113914)
For your References section:Semisynthetic biosensors for mapping cellular concentrations of nicotinamide adenine dinucleotides. Sallin O, Reymond L, Gondrand C, Raith F, Koch B, Johnsson K. Elife. 2018 May 29;7. pii: 32638. doi: 10.7554/eLife.32638. 32638 [pii] PubMed 29809136
