(Plasmid #115252)


Item Catalog # Description Quantity Price (USD)
Plasmid 115252 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number


  • Gene/Insert name
  • Species
    H. sapiens (human)
  • Mutation
    N72A, N199A
  • Entrez Gene
    NODAL (a.k.a. HTX5)
  • Promoter CMV
  • Tag / Fusion Protein
    • MYC-DYK (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site unknown (unknown if destroyed)
  • 5′ sequencing primer T7
  • 3′ sequencing primer hGH-PA-R
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Both N-glycosylation sites in the NODAL pro-domain are mutated . Please visit for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    NODAL-MYC-DYK-N72A-N199A was a gift from Lynne Postovit (Addgene plasmid # 115252 ; ; RRID:Addgene_115252)
  • For your References section:

    Genetically regulated human NODAL splice variants are differentially post-transcriptionally processed and functionally distinct. Findlay SD, Bilyk O, Lypka K, Waskiewicz AJ, Postovit L. (2018) bioRxiv 276170 10.1101/276170
