(Plasmid #117396)


Item Catalog # Description Quantity Price (USD)
Plasmid 117396 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.


  • Vector backbone
  • Modifications to backbone
    A gene encoding the Lac repressor (lacIQ allele) and a lac-controlled synthetic operon containing three genes encoding the antibacterial toxins HokB, GhoT, and TisB were inserted into the backbone via blunt-ligation into a blunted NdeI restriction site.
  • Vector type
    Bacterial Expression, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
  • Growth Temperature
  • Growth Strain(s)
  • Growth instructions
    Also carries a gentamicin selectable marker
  • Copy number
    High Copy


  • Gene/Insert name
  • Species
  • Insert Size (bp)
  • Promoter Ptac

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SpeI (destroyed during cloning)
  • 3′ cloning site SpeI (destroyed during cloning)
  • 5′ sequencing primer caaagggaatcaggggatct
  • 3′ sequencing primer gaggggtggaaatggagttt
  • (Common Sequencing Primers)

Resource Information

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTn7xKS-mPlum was a gift from Karen Guillemin (Addgene plasmid # 117396 ; ; RRID:Addgene_117396)
  • For your References section:

    Modernized Tools for Streamlined Genetic Manipulation and Comparative Study of Wild and Diverse Proteobacterial Lineages. Wiles TJ, Wall ES, Schlomann BH, Hay EA, Parthasarathy R, Guillemin K. MBio. 2018 Oct 9;9(5). pii: mBio.01877-18. doi: 10.1128/mBio.01877-18. 10.1128/mBio.01877-18 PubMed 30301859
