pCMV6M-Pak1 H83L H86L
(Plasmid #12211)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 12211 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 12211-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 12211-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    pCMV6
  • Backbone size w/o insert (bp) 4900
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Pak1
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    2000
  • Mutation
    PBD (p21-binding domain) mutant: H83L, H86L (see depositor comment below)
  • Entrez Gene
    PAK1 (a.k.a. IDDMSSD, PAKalpha, alpha-PAK, p65-PAK)
  • Tag / Fusion Protein
    • Myc (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SalI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer TCGTTTAGTGAACCGTCAG
  • 3′ sequencing primer GGAACTTCCAAGGCCAGGA
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Created by 3-way ligation of PCR products: B/Sac-Sac/Eco-Eco/B.

Pak1 may contain mutations G401S and L516I. Depositor states that this should not affect plasmid function.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCMV6M-Pak1 H83L H86L was a gift from Jonathan Chernoff (Addgene plasmid # 12211 ; http://n2t.net/addgene:12211 ; RRID:Addgene_12211)

  • For your References section:

    Human p21-activated kinase (Pak1) regulates actin organization in mammalian cells. Sells MA, Knaus UG, Bagrodia S, Ambrose DM, Bokoch GM, Chernoff J. Curr Biol. 1997 Mar 1. 7(3):202-10. 10.1016/S0960-9822(97)70091-5 PubMed 9395435
