EC.SurA.pTYB1.a21-281&390-428.wt
(Plasmid #12607)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 12607 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pTYB1
  • Backbone manufacturer
    New England Biolabs
  • Backbone size w/o insert (bp) 7280
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Escherichia coli surA delta PPIase domain 2
  • Alt name
    SurA(deltaP2)
  • Species
    E. coli
  • Insert Size (bp)
    900
  • Mutation
    residues 282-389 deleted
  • Tag / Fusion Protein
    • intein (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NdeI (not destroyed)
  • 3′ cloning site KpnI (not destroyed)
  • 5′ sequencing primer T7
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    EC.SurA.pTYB1.a21-281&390-428.wt was a gift from David McKay (Addgene plasmid # 12607 ; http://n2t.net/addgene:12607 ; RRID:Addgene_12607)
  • For your References section:

    The periplasmic molecular chaperone protein SurA binds a peptide motif that is characteristic of integral outer membrane proteins. Bitto E, McKay DB. J Biol Chem. 2003 Dec 5. 278(49):49316-22. 10.1074/jbc.M308853200 PubMed 14506253
