(Plasmid #135179)


Item Catalog # Description Quantity Price (USD)
Plasmid 135179 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
    pAAV-Ef1a-DIO hChR2(E123T/T159C)-EYFP (addgene plasmid #35509)
  • Backbone manufacturer
    addgene plasmid #35509
  • Backbone size w/o insert (bp) 4041
  • Total vector size (bp) 5176
  • Modifications to backbone
    Promoter and CDS parts were excised from the backbone plasmid by MluI and BamHI. TRE3G promoter and Clover were inserted.
  • Vector type
    Mammalian Expression, AAV

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert 1

  • Gene/Insert name
  • Species
    Aequorea victoria
  • Insert Size (bp)
  • Mutation
    a variant of GFP
  • GenBank ID
  • Promoter TRE3G

Cloning Information for Gene/Insert 1

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRI (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer nd
  • (Common Sequencing Primers)

Gene/Insert 2

  • Gene/Insert name
  • Species
  • Insert Size (bp)

Cloning Information for Gene/Insert 2

  • Cloning method Restriction Enzyme
  • 5′ cloning site MluI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer nd
  • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Clover was obtained from addgene plasmid #40259. TRE3G promoter was obtained from pTRE3G-ZsGreen1 of Clontech. The use of TRE3G is licensed from TETsystems Inc.

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

This AAV plasmid has been used in Abe et al., 2018 (PMID 30425625) and Lin et al, 2019 (PMID 30720427).

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAVTRE3_Clover was a gift from Tetsuo Yamamori (Addgene plasmid # 135179 ; ; RRID:Addgene_135179)
  • For your References section:

    Local and long-distance organization of prefrontal cortex circuits in the marmoset brain. Watakabe A, Skibbe H, Nakae K, Abe H, Ichinohe N, Rachmadi MF, Wang J, Takaji M, Mizukami H, Woodward A, Gong R, Hata J, Van Essen DC, Okano H, Ishii S, Yamamori T. Neuron. 2023 May 9:S0896-6273(23)00338-0. doi: 10.1016/j.neuron.2023.04.028. 10.1016/j.neuron.2023.04.028 PubMed 37196659
