(Plasmid #140593)


Item Catalog # Description Quantity Price (USD)
Plasmid 140593 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.


  • Vector backbone
  • Total vector size (bp) 8584
  • Modifications to backbone
    NAT (Nourseothricin) selection marker instead of URA3
  • Vector type
    Yeast Expression
  • Selectable markers
    NAT (Nourseothricin)

Growth in Bacteria

  • Bacterial Resistance(s)
  • Growth Temperature
  • Growth Strain(s)
  • Copy number


  • Gene/Insert name
    NDT1 with 5' and 3' UTRs
  • Alt name
    YIA6; YIL006W
  • Species
    S. cerevisiae (budding yeast)
  • Insert Size (bp)
  • Entrez Gene
    YIA6 (a.k.a. YIL006W, NDT1)
  • Promoter NDT1 promoter and 3'UTR

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer M13 rev caggaaacagctatgac
  • 3′ sequencing primer M13 fwd actggccgtcgttttac
  • (Common Sequencing Primers)

Resource Information

  • Terms and Licenses
  • Industry Terms
    • Not Available to Industry
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    YCplac33-NAT_NDT1 was a gift from David Sabatini (Addgene plasmid # 140593 ; ; RRID:Addgene_140593)
  • For your References section:

    MCART1/SLC25A51 is required for mitochondrial NAD transport. Kory N, uit de Bos J, van der Rijt S, Jankovic N, Güra M, Arp N, Pena IA, Prakash G, Chan SH, Kunchok T, Lewis, CA, Sabatini DM. Science Advances 09 Sep 2020: eabe5310 10.1126/sciadv.abe5310
