(Plasmid #154845)


Item Catalog # Description Quantity Price (USD)
Plasmid 154845 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
  • Total vector size (bp) 6813
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy


  • Gene/Insert name
    Stx5 (Short isoform)
  • Alt name
  • Alt name
    Syntaxin 5
  • Alt name
  • Species
    H. sapiens (human)
  • Insert Size (bp)
  • Mutation
    Lacks amino acids 1-54, enocdes short isoform of Stx5
  • GenBank ID
  • Entrez Gene
    STX5 (a.k.a. CDG2AA, SED5, STX5A)
  • Promoter CMV
  • Tags / Fusion Proteins
    • Streptavidin Binding Protein (SBP) (C terminal on insert)
    • mCitrine (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AscI (not destroyed)
  • 3′ cloning site XbaI (not destroyed)
  • 5′ sequencing primer IRES-F
  • 3′ sequencing primer pEGFP-all
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    str-KDEL_Stx5S-SBP-mCitrine was a gift from Geert van den Bogaart (Addgene plasmid # 154845 ; ; RRID:Addgene_154845)
  • For your References section:

    Congenital disorder of glycosylation caused by starting site-specific variant in syntaxin-5. Linders PTA, Gerretsen ECF, Ashikov A, Vals MA, de Boer R, Revelo NH, Arts R, Baerenfaenger M, Zijlstra F, Huijben K, Raymond K, Muru K, Fjodorova O, Pajusalu S, Ounap K, Ter Beest M, Lefeber D, van den Bogaart G. Nat Commun. 2021 Oct 28;12(1):6227. doi: 10.1038/s41467-021-26534-y. 10.1038/s41467-021-26534-y PubMed 34711829
