pMito-MtrxRFP2
(Plasmid #172324)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 172324 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 172324-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 172324-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    pCS2+
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    mitochondrial expression of human thioredoxin 2, fused with a redox-sensitive RFP through Gly-Ser-rich linker
  • Alt name
    MtrxRFP2 with mitochondrial localization sequence
  • Species
    Synthetic
  • Promoter CMV, SP6
  • Tags / Fusion Proteins
    • His-tag (N terminal on insert)
    • Mitochondria localization sequence (N terminal on insert)

Cloning Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

We recommend the use of pMito-MtrxRFP2 over pMito-TrxRFP1 (Plasmid #98997) for monitoring the redox of mitochondrial thioredoxin

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pMito-MtrxRFP2 was a gift from Huiwang Ai (Addgene plasmid # 172324 ; http://n2t.net/addgene:172324 ; RRID:Addgene_172324)

  • For your References section:

    Improved Red Fluorescent Redox Indicators for Monitoring Cytosolic and Mitochondrial Thioredoxin Redox Dynamics. Pang Y, Zhang H, Ai HW. Biochemistry. 2022 Mar 1;61(5):377-384. doi: 10.1021/acs.biochem.1c00634. Epub 2022 Feb 8. 10.1021/acs.biochem.1c00634 PubMed 35133140
