(Plasmid #176610)


Item Catalog # Description Quantity Price (USD)
Plasmid 176610 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Vector type
    Mammalian Expression, Lentiviral

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy


  • Gene/Insert name
    NeonGreen-tSH2 Syk
  • Species
    M. musculus (mouse), Synthetic
  • Mutation
  • Entrez Gene
    Syk (a.k.a. Sykb)

Cloning Information

  • Cloning method Gibson Cloning

Resource Information

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    NK83 was a gift from Meghan Morrissey (Addgene plasmid # 176610 ; ; RRID:Addgene_176610)
  • For your References section:

    Tight nanoscale clustering of Fcgamma receptors using DNA origami promotes phagocytosis. Kern N, Dong R, Douglas SM, Vale RD, Morrissey MA. Elife. 2021 Jun 3;10. pii: 68311. doi: 10.7554/eLife.68311. 10.7554/eLife.68311 PubMed 34080973
