Venus-7aa-ActA-pEGFP-C1
(Plasmid #177405)

• Purpose: To express Venus fused to mitochondria outer membrane targeting sequence "ActA". Venus faces the cytosol.
• Depositing Lab: David Andrews
• Depositing Organization: Sunnybrook Research Institute
  Located in Canada
• Publication: Osterlund et al Protocol Exchange (2022)

Backbone

• Vector backbone: pEGFP-C1
• Vector type: Mammalian Expression
• Selectable markers: Neomycin (select with G418)

Growth in Bacteria

• Bacterial Resistance(s): Kanamycin, 50 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: ActA tail anchor
• Alt name: Venus-ActA, V-ActA, VActA
• Species: Listeria monocytogenes
• Entrez Gene: actA (a.k.a. lmo0204)
• Promoter: CMV
• Tag / Fusion Protein:
  • Venus (N terminal on insert)

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ sequencing primer: TGACGCAAATGGGCGGTAGG
• 3′ sequencing primer: TCGCCCTTTGACGTTGGAGTCCAC

Resource Information

• A portion of this plasmid was derived from a plasmid made by: See gene entry for "actin assembly-inducing protein ActA" (NCBI Reference Sequence: WP_110138194.1). Here we have used only the C-terminal tail anchor sequence of this protein. Venus sequence received from Dr. Ray Truant (McMaster University).

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Depositor Comments

Transfection of this plasmid will express Venus-fused to the N-terminus of ActA tail anchor sequence: "LILAMLAIGVFSLGAFIKIIQLRKNN", which targets the mitochondrial outer membrane and signal correlates with mitotracker Red signal in cells. "7aa" indicates the 7 aa flexible linker region, "SGLRSRV" between Venus and the ActA targeting signal. This Venus protein contains an F224R mutation to make it monomeric.

DNA (Catalog # 177405-D50)

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

• Amount: 50 μg
• Concentration: 1 μg/μL
• Pricing: $495 USD
• Storage: 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

DNA (Catalog # 177405-D100)

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

• Amount: 100 μg
• Concentration: 1 μg/μL
• Pricing: $585 USD
• Storage: 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.
