(Plasmid #183869)


Item Catalog # Description Quantity Price (USD)
Plasmid 183869 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
    Thermo Fischer Scientific
  • Backbone size w/o insert (bp) 2974
  • Total vector size (bp) 5719
  • Vector type
    Mammalian Expression, CRISPR ; Donor template

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
    MYH10 homology arms with mRuby2-linker
  • Alt name
    Myosin heavy chain 10
  • Species
    H. sapiens (human)
  • Insert Size (bp)
  • Mutation
    Homology arms contain point mutations to remove the sgRNA target site
  • Entrez Gene
    MYH10 (a.k.a. NMMHC-IIB, NMMHCB)
  • Tag / Fusion Protein
    • mRuby2-linker (N terminal on insert)

Cloning Information

  • Cloning method Unknown
  • 5′ sequencing primer CAACTGCTTTAACACTTGTGCCTG
  • 3′ sequencing primer GTTCCTGATGAGGTGGTTAGCATAG
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pODN-mR2-MYH10 was a gift from Alisa Piekny (Addgene plasmid # 183869 ; ; RRID:Addgene_183869)
  • For your References section:

    Cytokinetic diversity in mammalian cells is revealed by the characterization of endogenous anillin, Ect2 and RhoA. Husser MC, Ozugergin I, Resta T, Martin VJJ, Piekny AJ. Open Biol. 2022 Nov;12(11):220247. doi: 10.1098/rsob.220247. Epub 2022 Nov 23. 10.1098/rsob.220247 PubMed 36416720
