Kv2.1 K+ channel scFv [K89/41]
(Plasmid #190496)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 190496 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pCDNA3.4
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 5428
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Kv2.1 K+ channel (Rattus norvegicus) recombinant scFV
  • Species
    M. musculus (mouse)
  • Entrez Gene
    Kcnb1 (a.k.a. DRK1PC, Kcr1-1, Kv2.1, Shab)
  • Promoter CMV
  • Tag / Fusion Protein
    • HA, Sortase, 6xHis (C terminal on insert)

Cloning Information

  • Cloning method Gibson Cloning

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

This is a recombinant antibody derived from RRID: AB_2922692.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Kv2.1 K+ channel scFv [K89/41] was a gift from James Trimmer (Addgene plasmid # 190496 ; http://n2t.net/addgene:190496 ; RRID:Addgene_190496)
  • For your References section:

    High-volume hybridoma sequencing on the NeuroMabSeq platform enables efficient generation of recombinant monoclonal antibodies and scFvs for neuroscience research. Mitchell KG, Gong B, Hunter SS, Burkart-Waco D, Gavira-O'Neill CE, Templeton KM, Goethel ME, Bzymek M, MacNiven LM, Murray KD, Settles ML, Froenicke L, Trimmer JS. Sci Rep. 2023 Sep 27;13(1):16200. doi: 10.1038/s41598-023-43233-4. 10.1038/s41598-023-43233-4 PubMed 37758930
