pCR-U6-gRNA-TRE3G-TdTomato
(Plasmid
#192658)
-
PurposeA plasmid encoding TRE3G sgRNA and TRE3G-promoter-TdTomato
-
Depositing Lab
-
Sequence Information
Ordering
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 192658 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
This material is available to academics and nonprofits only.
Backbone
-
Vector backbonepCR-Blunt II
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)NEB Stable
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameTdTomato
-
gRNA/shRNA sequenceTRE3G sgRNA: TACGTTCTCTATCACTGATA
-
SpeciesSynthetic
- Promoter U6, TRE3G
Cloning Information
- Cloning method TOPO Cloning
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pCR-U6-gRNA-TRE3G-TdTomato was a gift from Jeffrey Miner (Addgene plasmid # 192658 ; http://n2t.net/addgene:192658 ; RRID:Addgene_192658) -
For your References section:
Comparative analysis of dCas9-VP64 variants and multiplexed guide RNAs mediating CRISPR activation. Omachi K, Miner JH. PLoS One. 2022 Jun 28;17(6):e0270008. doi: 10.1371/journal.pone.0270008. eCollection 2022. 10.1371/journal.pone.0270008 PubMed 35763517
