(Plasmid #193552)


This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 193552 Standard format: Plasmid sent in bacteria as agar stab 1 $85


  • Vector backbone
  • Backbone manufacturer
  • Total vector size (bp) 6024
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number


  • Gene/Insert name
    Clathrin light chain A
  • Species
    M. musculus (mouse)
  • Insert Size (bp)
  • GenBank ID
  • Entrez Gene
    Clta (a.k.a. Lca)
  • Promoter CMV
  • Tags / Fusion Proteins
    • mEGFP (N terminal on backbone)
    • ShadowY (N terminal on insert)

Cloning Information

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Dr. W. Almers (Oregon Health and Science University)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please visit for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    EGFP-ShadowY-CLC was a gift from Justin Taraska (Addgene plasmid # 193552 ; ; RRID:Addgene_193552)
  • For your References section:

    A conformational switch in clathrin light chain regulates lattice structure and endocytosis at the plasma membrane of mammalian cells. Obashi K, Sochacki KA, Strub MP, Taraska JW. Nat Commun. 2023 Feb 9;14(1):732. doi: 10.1038/s41467-023-36304-7. 10.1038/s41467-023-36304-7 PubMed 36759616
