(Plasmid #193757)


Item Catalog # Description Quantity Price (USD)
Plasmid 193757 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone size w/o insert (bp) 1990
  • Total vector size (bp) 2647
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    Low Copy


  • Gene/Insert name
  • Species
  • Insert Size (bp)
  • Promoter PR

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site KpnI (unknown if destroyed)
  • 3′ cloning site XbaI (unknown if destroyed)
  • 5′ sequencing primer TGGTGAGTGTGATTAAACCAGAGA
  • 3′ sequencing primer AATGTTGCCTTCGGTTTTCC
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    PRC3MKO2 was a gift from Sangram Bagh (Addgene plasmid # 193757 ; ; RRID:Addgene_193757)
  • For your References section:

    A single layer artificial neural network type architecture with molecular engineered bacteria for reversible and irreversible computing. Sarkar K, Bonnerjee D, Srivastava R, Bagh S. Chem Sci. 2021 Nov 9;12(48):15821-15832. doi: 10.1039/d1sc01505b. eCollection 2021 Dec 15. 10.1039/d1sc01505b PubMed 35024106
