pcDNA3-Myc3-Nrf2-Flag3C E82G
(Plasmid #21560)

Print

Full plasmid sequence is not available for this item.

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 21560 Standard format: Plasmid sent in bacteria as agar stab 1 $94

Backbone

  • Vector backbone
    pcDNA3-myc3-Flag3C
  • Backbone size w/o insert (bp) 5547
  • Vector type
    Mammalian Expression
  • Selectable markers
    G418

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    nuclear factor (erythroid-derived 2)-like 2
  • Alt name
    NFE2L2
  • Alt name
    NRF2
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1822
  • Mutation
    Site directed mutagenesis of Nrf2 delta E82G.
  • GenBank ID
    Q16236
  • Entrez Gene
    NFE2L2 (a.k.a. HEBP1, IMDDHH, NRF2, Nrf-2)
  • Tags / Fusion Proteins
    • myc3 (N terminal on backbone)
    • Flag3 (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site AgeI (not destroyed)
  • 5′ sequencing primer T7
  • 3′ sequencing primer SP6
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3-Myc3-Nrf2-Flag3C E82G was a gift from Yue Xiong (Addgene plasmid # 21560)

  • For your References section:

    BTB protein Keap1 targets antioxidant transcription factor Nrf2 for ubiquitination by the Cullin 3-Roc1 ligase. Furukawa M, Xiong Y. Mol Cell Biol. 2005 Jan . 25(1):162-71. 10.1128/MCB.25.1.162-171.2005 PubMed 15601839
