gRNA3_NIPBL_Cas9-hGem-for_N-terminal_tagging
(Plasmid #217662)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 217662 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 217662-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 217662-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    pX330-U6-Chimeric_BB-CBh-hSpCas9-hGem-Bpil-P2A-mCherry
  • Backbone size w/o insert (bp) 9643
  • Total vector size (bp) 9346
  • Vector type
    Mammalian Expression, Bacterial Expression, CRISPR
  • Selectable markers
    mCherry

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    sgRNA3 for N terminal tagging of NIPBL
  • gRNA/shRNA sequence
    caccgtgtccccattactactcttg
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    20
  • Entrez Gene
    NIPBL (a.k.a. CDLS, CDLS1, IDN3, IDN3-B, Scc2)
  • Promoter U6

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BpiI (destroyed during cloning)
  • 3′ cloning site BpiI (destroyed during cloning)
  • 5′ sequencing primer GACTATCATATGCTTACCGT
  • 3′ sequencing primer GATGGGGAGAGTGAAGCAGAAC
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    gRNA3_NIPBL_Cas9-hGem-for_N-terminal_tagging was a gift from Daniel Gerlich (Addgene plasmid # 217662 ; http://n2t.net/addgene:217662 ; RRID:Addgene_217662)

  • For your References section:

    Cohesin-mediated DNA loop extrusion resolves sister chromatids in G2 phase. Batty P, Langer CC, Takacs Z, Tang W, Blaukopf C, Peters JM, Gerlich DW. EMBO J. 2023 Aug 15;42(16):e113475. doi: 10.15252/embj.2023113475. Epub 2023 Jun 26. 10.15252/embj.2023113475 PubMed 37357575
