H2B-RFP in pENTR1A (w507-1)
(Plasmid #22525)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 22525 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 22525-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 22525-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    pENTR1A
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 2289
  • Vector type
    Gateway Cloning

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Growth instructions
    TOP10F', 37oC
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Human Histone H2B -Heteractis crispa red fluorescent protein
  • Alt name
    H2B-HcRed
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1082
  • Entrez Gene
    H2BC21 (a.k.a. GL105, H2B, H2B-GL105, H2B.1, H2BE, H2BFQ, H2BGL105, H2BQ, HIST2H2BE)
  • Tag / Fusion Protein
    • HcRed (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Sal I (not destroyed)
  • 3′ cloning site Not I (not destroyed)
  • 5′ sequencing primer ENTRforw
  • 3′ sequencing primer ENTRrev
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

H2B-HcRed is of unknown origin.

Please note that H2B-DsRed runs at a higher molecular weight than it is supposed to (~ 2kb instead of ~1 kb) on an agarose gel. Both the original vector and the Entry vector containing the H2B-RFP show the same migration pattern. Depositor confirmed plasmid sequence with ENTRforw and ENTRrev. In addition, depositor expressed the H2B-RFP and confirmed its location to mitotic chromosomes.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    H2B-RFP in pENTR1A (w507-1) was a gift from Eric Campeau (Addgene plasmid # 22525 ; http://n2t.net/addgene:22525 ; RRID:Addgene_22525)
