(Plasmid #22817)


Item Catalog # Description Quantity Price (USD)
Plasmid 22817 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.


Growth in Bacteria

  • Bacterial Resistance(s)
  • Growth Temperature
  • Growth Strain(s)
  • Copy number


  • Gene/Insert name

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XbaI (unknown if destroyed)
  • 3′ cloning site EcoRV (unknown if destroyed)
  • 5′ sequencing primer tccatacccgtttttttggg
  • (Common Sequencing Primers)

Resource Information

  • Terms and Licenses
  • Industry Terms
    • Not Available to Industry

Depositor Comments

Addgene's QC sequence shows a 4bp gap with the depositor's provided sequence. The lab does not believe this affects the plasmid activity.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBTB-1 was a gift from Ryan Gill (Addgene plasmid # 22817 ; ; RRID:Addgene_22817)
  • For your References section:

    Broad host range vectors for stable genomic library construction. Lynch MD, Gill RT. Biotechnol Bioeng. 2006 May 5. 94(1):151-8. 10.1002/bit.20836 PubMed 16496398
