PurposeThe plasmid contains the Pleaides (Ple) MiniPromoter Ple155 derived from the human PCP2 gene and designed for expression in ON Bipolar cells of the retina.
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||29220||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 16454
Vector typeMammalian Expression ; High copy number homologous recombination plasmid for gene targeting at the mouse Hprt locus.
Growth in Bacteria
Copy numberHigh Copy
Alt namePurkinje cell protein 2
Insert Size (bp)1652
- Promoter MiniPromoter Ple155 from the human PCP2 gene
- Cloning method Restriction Enzyme
- 5′ cloning site SacI (unknown if destroyed)
- 3′ cloning site MluI (unknown if destroyed)
- 5′ sequencing primer Unknown (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
1 Korecki, A. J. et al. Twenty-Seven Tamoxifen-Inducible iCre-Driver Mouse Strains for Eye and Brain, Including Seventeen Carrying a New Inducible-First Constitutive-Ready Allele. Genetics 211, 1155-1177 (2019).
2 de Leeuw, C. N. et al. rAAV-Compatible MiniPromoters for Restricted Expression in the Brain and Eye. Molecular Brain 9, 52 (2016).
3 Scalabrino, M. L. et al. Intravitreal delivery of a novel AAV vector targets ON bipolar cells and restores visual function in a mouse model of complete congenital stationary night blindness. Hum Mol Genet 24, 6229-6239, doi:10.1093/hmg/ddv341, ddv341 [pii] (2015).
4 de Leeuw, C. N. et al. Targeted CNS delivery using human MiniPromoters and demonstrated compatibility with adeno-associated viral vectors. Mol Ther Methods Clin Dev 1, 1-15 (2014).
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pEMS1424 was a gift from Elizabeth Simpson (Addgene plasmid # 29220 ; http://n2t.net/addgene:29220 ; RRID:Addgene_29220)
For your References section:Human MiniPromoters for ocular-rAAV expression in ON bipolar, cone, corneal, endothelial, Muller glial, and PAX6 cells. Korecki AJ, Cueva-Vargas JL, Fornes O, Agostinone J, Farkas RA, Hickmott JW, Lam SL, Mathelier A, Zhou M, Wasserman WW, Di Polo A, Simpson EM. Gene Ther. 2021 Feb 2. pii: 10.1038/s41434-021-00227-z. doi: 10.1038/s41434-021-00227-z. 10.1038/s41434-021-00227-z PubMed 33531684
