(Plasmid #31950)


Item Catalog # Description Quantity Price (USD)
Plasmid 31950 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
  • Alt name
    photoactivatable dark-to-red TagRFP red fluorescent protein
  • Insert Size (bp)
  • Mutation
    R69S/F84W/Q139K/A147P/N148S/M151K/Y153K/S165V/H203R/R207I/V218W/C229S compared to TagRFP (but numbering relative to EGFP)
  • Promoter CMV
  • Tag / Fusion Protein
    • EGF receptor (EGFR) (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SacII (unknown if destroyed)
  • 3′ cloning site BsrGI (unknown if destroyed)
  • 5′ sequencing primer cggtaggcgtgtacggtgggag
  • 3′ sequencing primer gttcagggggaggtgtgggagg
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEGFR-PATagRFP was a gift from Vladislav Verkhusha (Addgene plasmid # 31950 ; ; RRID:Addgene_31950)
  • For your References section:

    Bright monomeric photoactivatable red fluorescent protein for two-color super-resolution sptPALM of live cells. Subach FV, Patterson GH, Renz M, Lippincott-Schwartz J, Verkhusha VV. J Am Chem Soc. 2010 May 12;132(18):6481-91. 10.1021/ja100906g PubMed 20394363
