pTK5
(Plasmid #37391)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 37391 Standard format: Plasmid sent in bacteria as agar stab 1 $65

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pEGFP-C1
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    ACTR1A
  • Alt name
    ARP1
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1131
  • Entrez Gene
    ACTR1A (a.k.a. ARP1, Arp1A, CTRN1)
  • Promoter CMV
  • Tags / Fusion Proteins
    • mCherry (N terminal on insert)
    • TEV (N terminal on insert)
    • S-tag (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer GGCATGGACGAGCTGTACAAG
  • 3′ sequencing primer GCATTCATTTTATGTTTCAGG
  • (Common Sequencing Primers)

Resource Information

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTK5 was a gift from Iain Cheeseman (Addgene plasmid # 37391 ; http://n2t.net/addgene:37391 ; RRID:Addgene_37391)
  • For your References section:

    Chromosome- and spindle-pole-derived signals generate an intrinsic code for spindle position and orientation. Kiyomitsu T, Cheeseman IM. Nat Cell Biol. 2012 Feb 12;14(3):311-7. doi: 10.1038/ncb2440. 10.1038/ncb2440 PubMed 22327364
