Purposeexpression of Xt-VSP in Xenopus oocytes or mammalian cells
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||51887||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
Vector typeMammalian Expression ; Xenopus oocyte expression
Growth in Bacteria
Copy numberHigh Copy
- Promoter CMV
- Cloning method Restriction Enzyme
- 5′ cloning site KpnI (not destroyed)
- 3′ cloning site EcoRV (not destroyed)
- 5′ sequencing primer CMV-F
- 3′ sequencing primer BGH Reverse (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
Plasmid encoding Xt-VSP (NM_001015951.2, clone # 77E02) was purchased from GeneService (Cambridge, UK).
*There is a Y242H aa residue substitution compared to the listed genbank ref seq. This amino acid difference is believed to be a polymorphism that does not affect function.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pcDNA3-Xt-VSP was a gift from Laurinda Jaffe (Addgene plasmid # 51887 ; http://n2t.net/addgene:51887 ; RRID:Addgene_51887)
For your References section:Voltage sensitive phosphoinositide phosphatases of Xenopus: their tissue distribution and voltage dependence. Ratzan WJ, Evsikov AV, Okamura Y, Jaffe LA. J Cell Physiol. 2011 Nov;226(11):2740-6. doi: 10.1002/jcp.22854. 10.1002/jcp.22854 PubMed 21618529
